HULL CONSTRUCTION

Heavy duty GRP Moulding, hand laid to Northshore Nordseal laminating system incorporating multi-axial and unidirectional reinforcements. Thickness increases progressively towards the keel area. The keel box is an integral part of the hull lay-up and sandwich construction stiffening runs the entire length of the hull topsides. All main bulkheads are bonded into the hull.

• Gelcoat colour: LR25113 Southerly Blue Boot top stripes: Off

• White 3969

• Style lines: Off White

• Underwater finish: Clear gelcoat / Antifoul



DECK CONSTRUCTION

Hand laid GRP. Sandwich type construction using balsa core stiffening , with marine plywood in high stress areas where fittings are positioned. Heavily stressed areas are additionally reinforced with unidirectional glass reinforcement, The deck is bonded to the hull through the entire length and to all main bulkheads resulting in a strong an integrated unit. Teak cappings are used to cover the hull to deck joint upstand.

• Gelcoat colour: Off White 3969

• Ring deck: Teak laid

​

VARIABLE DRAFT KEEL

The fixed ballast is an iron casting which acts as a grounding plate and as transverse stiffening for the keel unit. It is fitted into a recess in the hull in the area of the keel box with stainless steel bolts. The aerofoil swing keel is cast iron and incorporates a stainless steel pivot at the leading edge. The swing keel is raised and lowered by a hydraulic ram powered by an electrically driven pump with a manual back up. All hydraulics are easily accessible for maintenance. A keel control panel and gauge showing keel position is fitted at the wheel pedestal. A removeable stainless steel pin positioned to enable the keel to be locked in the “UP” position.

​

ENGINE

• Yanmar 3YM30 21.3kW (30hp) 3 cylinder fresh water cooled diesel engine

• Reduction/reverse gear

• 60 amp alternator
  Bronze stern tube with water lubricated stern gland

• Stainless steel propeller shaft

• Bronze three bladed propeller

• Substantial skeg fitted on centreline to protect propeller and rudders when yacht is dried out

• Non-metallic fuel tank under cabin sole below chart table – capacity 182 litres/40 gallons, with sediment trap and line filter

• Non-metallic water strainer with removeable filter

• 12V electric ventilator

• Sound deadening to engine box

• Hinge up panels at either end of engine box for access

• Engine box can be completely removed for maintenance.

​

BOW THRUSTER

• Vetus 55kgf thrust bow thruster

​

ELECTRICS

• 12 Volt system

• Two heavy duty batteries charged from engine alternator, one for engine, one for domestic use (new 2019

• Sterling battery charger 30amp

• Isolating switches

• Cabin lighting throughout

• Reading lights over bunks

• Chart light over navigation table

• Full navigation light system, incorporating bow light, stern light, masthead tricolour light with all round white anchor light, deck flood light and steaming light.

• Circuit breakers on main panel

• 12V interior socket, cigarette lighter type, fitted to navigation area

• 240v Ring main, with 3 double outlet sockets, earth leakage circuit breaker and connection cable with plug for shore connection

• 1kW Immersion heater fitted to engine calorifier

• Honda 500 portable generator



NAVIGATION & ELECTRONICS

• Garmin chart plotter

• Echomax radar reflector

• Garmin fish finder C160

• ICOM VHF handset and charger station

• Entel VHF hand set, desk charger and 12V battery charger

• 2 Cobra VHF marine handsets and 12V chargers

• Ball and cone set

• Grundig radio/CD player with cockpit speakers

​

ENGINEERING

• Holding tank system for heads. Heads pumps to sea or tank.

​

WATER SYSTEMS & PUMPS

• Pressurised hot and cold water system

• Mixer tap to galley sink

• Mixer tap in heads compartment

• Non-metallic water tank under aft end of dinette – Capacity 205 litres/45 gallons

• Hot water provided by engine calorifier unit

• Electric sump pump to shower tray

• One manual bilge pump

• One electric submersible bilge pump

​

STEERING

• Semi balanced twin rudders

• Pedestal mounted stainless steel cockpit wheel

• Lewmar/Whitlock Cobra steering system Single lever engine control

• Emergency steering system

• 6” main steering compass and compass guard

​​

SPARS & RIGGING

• Selden masthead rig

• Double swept back spreaders

• Selden anodised aluminium spars finished in silver

• Internal halyards

• 1 x 19 stainless steel wire standing rigging with swage toggle fork chrome bronze rigging screws

• Backstay with manual jib

• Furlex headsail reefing system

• Single line reefing led to aft cockpit for mainsail

• Solid kicker

• Kicker, main halyard, topping lift, outhaul and 2 reefs lead aft

• Genoa halyard at mast

• Burgee and signal halyards

• Sail control lead aft across pilot house

• Lewmar size 8 winch on mast

​

SAILS

• Dacron sails

• Self tacking furling jib

• Mainsail with four battens and mast sliders (bottom batten missing) Mainsail cover in CJ Marine red canvas (renewed in 2018)

​​

COCKPIT

• Aft cockpit

• Self draining

• Teak laid to cockpit seats
  Teak laid to cockpit sole

• Good access aft for boarding through transom

• Telescopic stern boarding ladder

• Large cockpit locker to port

• Gas bottle stowage in cockpit locker to starboard

• Cave locker in starboard cockpit coaming

• Sliding acrylic companionway hatch with washboard

• Companionway security bar

• Instrument panel above hatchway

• Two winch handle pockets

• Steering pedestal

• Two safety harness eyes

• Spray hood with stainless steel frame, canvas renewed in 2018 by CJ Marine in red Cockpit enclosure with stainless steel frame, canvas renewed in 2018 by CJ Marine in red

​

​
